| COLOUR |
Gun metal (matt) |
CASSETTE |
Shimano LG400, 11-48T, 10 speed |
| FRAME |
6061-T6 aluminium, multi-shaped tubing; Single Chain Ring (SCR) 1x-specific design; 1.125–1.5in tapered Zero-Stack headtube; full 300mm reamed depth 30.9mm seat tube; Post Mount 180mm disc dropout; SRAM UDH spec derailleur hanger; 12mm x 148mm Boost. |
CHAIN |
KMC eGlide, 118 links, 10 speed |
| FORK |
Suntour XCR36X, 130mm travel, 44mm offset, Black coating, adjustable compression and rebound, tapered steerer, 110mm x 15mm Boost |
CRANKSET |
Whyte 155mm length ISIS crank arms, direct mount 36T chainring, narrow wide |
| REAR SHOCK |
N/A |
BOTTOM BRACKET |
N/A |
| HEADSET |
ZS56 upper / lower headset cups for 1 1/8in upper and 1.5in lower with sealed bearings |
SEATPOST |
TranzX dropper post, 30.9mm, frame size specific drop (size S 150mm drop; sizes M-XL 170mm drop) |
| REAR HUB |
Alloy, e-bike specific, double sealed cartridge bearings, 12mm x 148mm Boost spacing, nine degree micro engagement four pawl, 32 hole, HG freehub |
SEAT |
Whyte Custom |
| FRONT HUB |
Alloy, 15mm x 110mm Boost spacing, 32 hole |
BAR |
Whyte 6061 alloy, 30mm rise, 35mm bar bore, 760mm wide |
| SPOKES |
2.0mm, black stainless, brass nipples |
STEM |
Whyte alloy, 40mm extension, 35mm bar bore |
| RIMS |
Whyte eMTB, sleeved joint, 30mm internal width, tubeless ready, 32 hole |
GRIPS |
Whyte Trail lock-on |
| TYRES |
Maxxis Rekon 29 x 2.6in (front and rear, sizes M-XL) / 27.5 x 2.6in (front and rear, size S) |
BRAKES FRONT |
Tektro M5141 hydraulic disc brake, four piston, 203mm diameter disc rotor |
| SHIFT LEVERS |
Shimano CUES U6000, 10 speed, band on clamp |
BRAKES REAR |
Tektro M5141 hydraulic disc brake, four piston,180mm diameter disc rotor, Avinox tone wheel incorporated in rotor |
| FRONT MECH |
N/A |
BRAKE LEVERS |
Tektro M5141 |
| REAR MECH |
Shimano CUES U6000, 10 speed |
PEDALS |
Fibre reinforced composite platform |
| WEIGHT |
TBC |
|
|
